Saving RNN Computations with a Neuron-Level Fuzzy Memoization Scheme

Recurrent Neural Networks (RNNs) are a key technology for applications such as automatic speech recognition or machine translation. Unlike conventional feed-forward DNNs, RNNs remember past information to improve the accuracy of future predictions and, therefore, they are very effective for sequence processing problems. For each application run, recurrent layers are executed many times for processing a potentially large sequence of inputs (words, images, audio frames, etc.). In this paper, we observe that the output of a neuron exhibits small changes in consecutive invocations.~We exploit this property to build a neuron-level fuzzy memoization scheme, which dynamically caches each neuron's output and reuses it whenever it is predicted that the current output will be similar to a previously computed result, avoiding in this way the output computations. The main challenge in this scheme is determining whether the new neuron's output for the current input in the sequence will be similar to a recently computed result. To this end, we extend the recurrent layer with a much simpler Bitwise Neural Network (BNN), and show that the BNN and RNN outputs are highly correlated: if two BNN outputs are very similar, the corresponding outputs in the original RNN layer are likely to exhibit negligible changes. The BNN provides a low-cost and effective mechanism for deciding when fuzzy memoization can be applied with a small impact on accuracy. We evaluate our memoization scheme on top of a state-of-the-art accelerator for RNNs, for a variety of different neural networks from multiple application domains. We show that our technique avoids more than 26.7\% of computations, resulting in 21\% energy savings and 1.4x speedup on average.

CREW: Computation Reuse and Efficient Weight Storage for Hardware-accelerated MLPs and RNNs

Deep Neural Networks (DNNs) have achieved tremendous success for cognitive applications. The core operation in a DNN is the dot product between quantized inputs and weights. Prior works exploit the weight/input repetition that arises due to quantization to avoid redundant computations in Convolutional Neural Networks (CNNs). However, in this paper we show that their effectiveness is severely limited when applied to Fully-Connected (FC) layers, which are commonly used in state-of-the-art DNNs, as it is the case of modern Recurrent Neural Networks (RNNs) and Transformer models. To improve energy-efficiency of FC computation we present CREW, a hardware accelerator that implements Computation Reuse and an Efficient Weight Storage mechanism to exploit the large number of repeated weights in FC layers. CREW first performs the multiplications of the unique weights by their respective inputs and stores the results in an on-chip buffer. The storage requirements are modest due to the small number of unique weights and the relatively small size of the input compared to convolutional layers. Next, CREW computes each output by fetching and adding its required products. To this end, each weight is replaced offline by an index in the buffer of unique products. Indices are typically smaller than the quantized weights, since the number of unique weights for each input tends to be much lower than the range of quantized weights, which reduces storage and memory bandwidth requirements. Overall, CREW greatly reduces the number of multiplications and provides significant savings in model memory footprint and memory bandwidth usage. We evaluate CREW on a diverse set of modern DNNs. On average, CREW provides 2.61x speedup and 2.42x energy savings over a TPU-like accelerator. Compared to UCNN, a state-of-art computation reuse technique, CREW achieves 2.10x speedup and 2.08x energy savings on average.

Boosting LSTM Performance Through Dynamic Precision Selection

The use of low numerical precision is a fundamental optimization included in modern accelerators for Deep Neural Networks (DNNs). The number of bits of the numerical representation is set to the minimum precision that is able to retain accuracy based on an offline profiling, and it is kept constant for DNN inference. In this work, we explore the use of dynamic precision selection during DNN inference. We focus on Long Short Term Memory (LSTM) networks, which represent the state-of-the-art networks for applications such as machine translation and speech recognition. Unlike conventional DNNs, LSTM networks remember information from previous evaluations by storing data in the LSTM cell state. Our key observation is that the cell state determines the amount of precision required: time steps where the cell state changes significantly require higher precision, whereas time steps where the cell state is stable can be computed with lower precision without any loss in accuracy. Based on this observation, we implement a novel hardware scheme that tracks the evolution of the elements in the LSTM cell state and dynamically selects the appropriate precision in each time step. For a set of popular LSTM networks, our scheme selects the lowest precision for more than 66% of the time, outperforming systems that fix the precision statically. We evaluate our proposal on top of a modern accelerator highly optimized for LSTM computation, and show that it provides 1.56x speedup and 23% energy savings on average without any loss in accuracy. The extra hardware to determine the appropriate precision represents a small area overhead of 8.8%.

LSTM-Sharp: An Adaptable, Energy-Efficient Hardware Accelerator for Long Short-Term Memory

The effectiveness of LSTM neural networks for popular tasks such as Automatic Speech Recognition has fostered an increasing interest in LSTM inference acceleration. Due to the recurrent nature and data dependencies of LSTM computations, designing a customized architecture specifically tailored to its computation pattern is crucial for efficiency. Since LSTMs are used for a variety of tasks, generalizing this efficiency to diverse configurations, i.e., adaptiveness, is another key feature of these accelerators. In this work, we first show the problem of low resource-utilization and adaptiveness for the state-of-the-art LSTM implementations on GPU, FPGA and ASIC architectures. To solve these issues, we propose an intelligent tiled-based dispatching mechanism that efficiently handles the data dependencies and increases the adaptiveness of LSTM computation. To do so, we propose LSTM-Sharp as a hardware accelerator, which pipelines LSTM computation using an effective scheduling scheme to hide most of the dependent serialization. Furthermore, LSTM-Sharp employs dynamic reconfigurable architecture to adapt to the model's characteristics. LSTM-Sharp achieves 1.5x, 2.86x, and 82x speedups on average over the state-of-the-art ASIC, FPGA, and GPU implementations respectively, for different LSTM models and resource budgets. Furthermore, we provide significant energy-reduction with respect to the previous solutions, due to the low power dissipation of LSTM-Sharp (383 GFLOPs/Watt).

(Pen-) Ultimate DNN Pruning

DNN pruning reduces memory footprint and computational work of DNN-based solutions to improve performance and energy-efficiency. An effective pruning scheme should be able to systematically remove connections and/or neurons that are unnecessary or redundant, reducing the DNN size without any loss in accuracy. In this paper we show that prior pruning schemes require an extremely time-consuming iterative process that requires retraining the DNN many times to tune the pruning hyperparameters. We propose a DNN pruning scheme based on Principal Component Analysis and relative importance of each neuron's connection that automatically finds the optimized DNN in one shot without requiring hand-tuning of multiple parameters.

E-PUR: An Energy-Efficient Processing Unit for Recurrent Neural Networks

Recurrent Neural Networks (RNNs) are a key technology for emerging applications such as automatic speech recognition, machine translation or image description. Long Short Term Memory (LSTM) networks are the most successful RNN implementation, as they can learn long term dependencies to achieve high accuracy. Unfortunately, the recurrent nature of LSTM networks significantly constrains the amount of parallelism and, hence, multicore CPUs and many-core GPUs exhibit poor efficiency for RNN inference. In this paper, we present E-PUR, an energy-efficient processing unit tailored to the requirements of LSTM computation. The main goal of E-PUR is to support large recurrent neural networks for low-power mobile devices. E-PUR provides an efficient hardware implementation of LSTM networks that is flexible to support diverse applications. One of its main novelties is a technique that we call Maximizing Weight Locality (MWL), which improves the temporal locality of the memory accesses for fetching the synaptic weights, reducing the memory requirements by a large extent. Our experimental results show that E-PUR achieves real-time performance for different LSTM networks, while reducing energy consumption by orders of magnitude with respect to general-purpose processors and GPUs, and it requires a very small chip area. Compared to a modern mobile SoC, an NVIDIA Tegra X1, E-PUR provides an average energy reduction of 92x.
